DigiTech Bass Whammy Pitch Shifter for Bass Guitar Effect Pedal

Legendary pitch shifting effect for bass guitar

The next generation Bass Whammy uses the most advanced pitch detection and polyphonic note tracking technology to create the world’s best pitch shifting effect pedal optimized for bass. The Bass Whammy maintains the classic settings from the original with many modern upgrades. With two different tracking modes, Classic and Chord, the Bass Whammy gives players the ability to recreate the shift glitch effects from the original or get the smooth pitch shift effect. Chord mode uses advanced polyphonic tracking algorithms for a more exact and smooth pitch shift effect while Classic maintains the tracking artifacts of the original Whammy. The Bass Whammy is true bypass, MIDI controllable, and uses a 9V DC power supply to easily integrate into your existing pedalboard.

Item# BASS WHAMMY-V-01

General Specifications

Sample Rate: 44.1 kHz
Frequency Response: 20Hz–20kHz
Signal to Noise Ratio: > -105 dB (A weighted); ref = max level, 22 kHz bandwidth
THD0.004% @ 1 kHz; ref = 1 dBu w/ unity gain
A/D Conversion: 24 bit
D/A Conversion: 24 bit
Power Consumption: 2.4 Watts (< 265 mA @ 9 VDC)
Power Requirements: 9 VDC External Adapter

Audio Output

Output Type: 1/4” Unbalanced TS
Max Output: Level+10 dBu
Output Impedance: 1 kΩ

Audio Input

Instrument Input Type: 1/4” Unbalanced TS
Max Input Level: +5 dBu
Input Impedance: 1 MΩ
MIDI Input: 5-Pin Din
